Product Overview
Lub 5.12kWh Cov Phab Ntsa Nyob Hauv Tsev-Mounted Lithium Roj teeb yog lub zog txuag kev daws teeb meem uas tsim los rau cov tsev nyob niaj hnub hnub ci, kev siv hluav taws xob thaum muaj xwm txheej ceev, thiab kev tswj hwm lub zog hauv tsev ntse.
Raws li xyoo dhau los ntawm kev lag luam kev paub dhau los thiab kev xa tawm thoob ntiaj teb, qhov siab - phab ntsa ua tau zoo- cov roj teeb mounted muab kev nyab xeeb tshwj xeeb, lub neej ntev tshaj li 6,000 cycles, ruaj khov zog tso tawm, thiab kev ntseeg siab ntawm lub cev. Nws sleek, compact structural tsim thiab saj zawg zog installation muaj peev xwm ua rau nws qhov kev xaiv zoo tshaj plaws rau cov tswv tsev, hnub ci system installers, lub zog distributors, thiab thoob ntiaj teb cov neeg koom tes.
Tsim los khaws cov khoom siv hluav taws xob txuas ntxiv uas tsim los ntawm cov tshuab photovoltaic, chav tsev no ua kom lub zog siv tau zoo thaum lub sijhawm hluav taws xob siab tshaj plaws lossis cov phiaj xwm tsis npaj txhij. Nruab nrog lub ntse roj teeb tswj System (BMS), ntau- txheej txheej tiv thaiv kev nyab xeeb, thiab seamless parallel scalability, nws muab kev nyab xeeb, muaj txiaj ntsig zoo, thiab tus nqi- lub hauv paus muaj zog txuag tau txhawb nqa los ntawm kev ua raws li thoob ntiaj teb nruj thiab 10 xyoo lav.
Cov yam ntxwv tseem ceeb
Advanced LiFePO4 Cell Technology Tsim los siv qib siab -qib Lithium Iron Phosphate chemistry, lub roj teeb tau lees paub kev nyab xeeb zoo tshaj plaws, zoo thermal stability, thiab kev ua haujlwm ntev dua piv rau lithium lithium{2}}ion technologies.
Optimal 5.12kWh Zog Cia Peev Xwm Nrog lub zog muaj peev xwm ntawm 5.12kWh (51.2V, 100Ah), chav tsev no ntaus kev lag luam- tus qauv qab zib qhov chaw rau kev siv hluav taws xob hauv tsev niaj hnub, hnub ci tus kheej - kev siv tau zoo, thiab kev siv hluav taws xob thaub qab.
Intelligent Battery Management System Cov kev tswj xyuas cov roj teeb ntse sib txuas txuas ntxiv taug qab cov haujlwm ua haujlwm tsis tu ncua thiab tiv thaiv lub roj teeb los ntawm qhov tseeb - lub sijhawm tswj cov txheej txheem.
Chaw-Txuag Phab Ntsa-Mounted Design Engineered tshwj xeeb rau cov chaw nyob huv si thiab niaj hnub, phab ntsa-mounted architecture tshem tawm clutters thiab khaws cia qhov chaw muaj txiaj ntsig hauv pem teb.
Yooj Yim Modular Capacity Expansion Lub system architecture txhawb kev sib txuas ntawm ntau lub roj teeb, tso cai rau cov neeg siv los ntsuas qhov muaj peev xwm cia tsis muaj zog raws li tsev neeg xav tau kev loj hlob.
Technical Specifications
| Parameter | Specification |
| Hom roj teeb | Lithium Hlau Phosphate (LiFePO4) |
| Rated Zog | 5.12 kWm |
| Nominal voltage | 51.2 V |
| Rated Peev Xwm | 100 Aw |
| Roj teeb Module Hom | Phab ntsa-Mounted Residential Battery |
| Kev khiav hauj lwm voltage | 44.8V rau 57.6V |
| Pom zoo them tam sim no | 50 A |
| Maximum Charging Tam sim no | 100 A |
| Maximum Discharge Current | 100 A |
| Lub neej voj voog | Ntau dua lossis sib npaug rau 6,000 Cycles |
| Round -Trip Efficiency | Ntau dua lossis sib npaug li 95 feem pua |
| Kev sib txuas lus Interface | TSI / RS485 |
| Txoj Kev Txhim Kho | Phab ntsa-Mounted |
| Txoj kev txias | Ntuj Txias |
| Qib tiv thaiv | IP Rated Design (Yeem) |
| Ua haujlwm kub | -20 ° C rau 55 ° C |
| Cia Kub | -20 ° C mus rau 45 ° C |
| Humidity Range | 5% mus rau 95% RH |
| Cov ntawv pov thawj thiab kev ua raws cai | CE, UN38.3, IEC62619, UL1973 (raws li muaj) |
| Warranty | 10-xyoo txwv Warranty |
| Daim ntawv thov tseem ceeb | Chaw Nyob Zog Cia thiab Thaub qab |
Hom Daim Ntawv Thov Scenarios
Solar Energy Storage Chaw Nyob:Pairs seamlessly nrog rooftop photovoltaic panels cia lub hnub ci zog rau yav tsaus ntuj siv.
Emergency Backup Power Systems:Tsis siv neeg muab hluav taws xob tsis cuam tshuam rau cov khoom tseem ceeb hauv tsev thaum lub sij hawm tam sim no daim phiaj hluav taws xob.
Tawm -Grid Energy Systems:Muab kev ntseeg siab, hluav taws xob ywj pheej rau cov tsev nyob deb, cabins, thiab cov khoom nyob deb nroog.
Smart Home Integration:Integrate smoothly nrog hybrid inverters thiab tsev zog tswj platforms rau automated zog teem sij hawm.
System Configuration Flow:Solar Photovoltaic Panels -> Hybrid Inverter -> 5.12kWh Wall-Mounted Lithium Battery ->Chaw Nyob Loads
OEM thiab ODM Customization rau Cov Neeg Koom Tes Thoob Ntiaj Teb
Peb muab cov khoom lag luam zoo tshaj plaws thiab cov chaw tsim khoom tsim thawj cov kev pabcuam raws li cov neeg xa khoom thoob ntiaj teb, cov neeg koom ua ke, thiab cov tswv lag luam tab tom nrhiav los tsim kom muaj kev sib tw ua lag luam hauv zos.
Visual Customization:Cov khoom lag luam pom zoo, xim schemes, thiab cov qauv tsim khoom lag luam.
Private Labeling:Kev cai logos, nameplates, thiab localized khoom ntim tsim.
Protocol Adaptation:Kev cai kev sib txuas lus raws tu qauv teeb tsa rau seamless kev koom ua ke nrog thib peb - tog hybrid inverters.
Specification Kho:Kho kho vajtse lossis firmware xaiv raws li cov kev cai hauv cheeb tsam.
Cov lus nug nquag
Q: Dab tsi yog qhov kev pab cuam lub neej ntawm lub roj teeb?
A: Lub roj teeb yog tsim los rau lub neej ua haujlwm ntev, ua tiav ntau dua 6,000 tus nqi thiab tawm mus raws li cov qauv ntsuas, txhawb nqa los ntawm txoj cai lav 10 xyoo. Lub neej ntev tiag tiag nyob ntawm kev ua haujlwm xws li qhov kub thiab txias, qhov tob ntawm qhov tso tawm, thiab kev saib xyuas ib puag ncig.
Q: Ntau lub roj teeb puas tuaj yeem txuas nrog rau tib lub sijhawm?
A: Yog. Cov qauv tsim qauv txhawb nqa kev nthuav dav, tso cai rau cov neeg siv kom nce tag nrho lub zog cia muaj peev xwm muaj kev nyab xeeb raws li qhov xav tau loj hlob.
Q: Cov inverters twg tau tshaj cov roj teeb no?
A: Nruab nrog tus qauv CAN thiab RS485 kev sib txuas lus kev sib txuas lus, lub roj teeb tau zoo tshaj plaws nrog rau feem ntau lub ntiaj teb hybrid inverter hom.
Q: Puas yog kev txhim kho yuav tsum tau ua?
A: Thaum lub phab ntsa-mounted qauv yog tsim los rau ncaj qha installation thiab txij nkawm, peb ib txwm pom zoo rau kev txhim kho los ntawm cov kws tshaj lij uas tau lees paub los lav qhov kev nyab xeeb thiab kev ua haujlwm zoo.
